Fjord Audio C-100 Balanced Valve Line Stage Preamp
Ex demo midel. Boxed with one year warranty.
Fjord Audio c-100 balanced linestage Full Difference Circuit on Pure Tube Circuit Maximize channel separation with a completely independent channel structure of the signal system from input to output. High Fidelity signal design with Zero Feedback circuit and Class A. UTS (Upper Tube Set) method blocks. Low harmonic noise from vacuum tubes Interior design reminiscent of a super car engine room Adoption of power separation structure and complete channel separation power method THD (0.005%), Dynamic Range that overcomes the limitations of tube Precise 64 Steps Attenuator Gain Controller used to relay-switched Attenuator volume control Visibility provided by applying OLDE display Specifications Model Name : C100 Circuit Type : Tube Line Pre Amplifier Circuit Design : Zero Feedback Number of Channels : 2 Class Type : Class A Used Tubes : 12AU7 * 4, 12AT7 * 2 Output Level : 5Vrms (Balanced) Input Impedance : 100K Output Impedance : 220ohm T.H.D : 0.005% SNR : 100dB Frequency Response : 10Hz ~ 100kHz (-1dB) Power Consumption : 35 W Input : 6 × XLR (BALANCED) Output : 1 x XLR (BALANCED) Main AC Power in : 220VAC (210~230VAC available) Size (W x H x D)mm : Main 460 * 130 * 325, Power 460 * 130 * 325 Weight : Main 13.9kg, Power 18.3kg
